NUMECA FINE / Open 10.1 (x64)

[pierxetran]

NUMECA FINE / Open 10.1 (x64) | 3.2 GB

FINE/Open with OpenLabs is a powerful CFD Flow Integrated Environment dedicated to complex internal and external flows.

It can solve any flow, from incompressible to low and high speed flows. It combines completely unstructured hexahedral grids with an efficient preconditioned compressible solver with fast agglomerated mulid acceleration and adaptation techniques.
FINE/Open with OpenLabs allows users to freely develop and exchange physical models in CFD, with a new open approach to CFD. Complex programming tasks are avoided through the usage of an easy meta-language. Users can develop, improve and customize physical and numerical models as for instance:

Transport equations (convection-diffusion-source)

Steady or unsteady source terms (heat, force, mass)

Diffusion coefficients

Algebraic relations

Initial and boundary conditions

Turbulence models, combustion models, radiation models

Atmospheric boundary layer models,

Actuator disk simulations,

Soot modeling

HEXPRESS:

Full Hexahedral Grids (no prism, no tetrahedra, no pyramid)

Direct CAD import capabilities

CAD manipulation and decomposition tools

Mesh wizard for rapid solution set-up and easy back and forth operation

Buffer cell and boundary layer insertion for high quality cells in boundary layer regions

Automatic refinement procedures based on user defined sensors either next to solid walls or at specified area in the domain

Multi domain capabilities allowing the treatment of CHT and multi-part geometry models

Full non-matching multi-block connection, allowing multi-row turbomachinery meshing

FINE/Open flow solver:

One single code for all types of fluids (incompressible, low-compressible, condensable and fully compressible) and speed (low speed to hypersonic regime)

Acceleration with the CPU-Booster module provides 3-5 s gain in convergence speed

Embedded fluid structure interaction with the Modal and Flutter Analysis module

Mulid convergence acceleration

Multidomain capability

Combustion

Radiation

Lagrangian multiphase

Cavitation

Multispecies reacting flows

Thermodynamics tables and combustion tables generation

Python scripting technology

OpenLabs:

OpenLabs allows users to customize or add physical models

Flexible and user-friendly Graphical User Interface

Users don't need to care about programming details and code structure

OpenLabs can be used in a wide variety of industrial and acad applications

Identical computing and memory costs compared to source-coded models

Free access to all FINE/Open community

CFView:

Multi-projects and multi-views graphical user interface

Python scripting technology
